Symposium on Compositional Structures

As I type this, sitting in a lecture hall at the Lorentz Center, Jamie Vicary, University of Birmingham and University of Oxford, is announcing a new series of meetings:

• Symposium on Compositional Structures.

The website, which will probably change, currently says this:

Symposium on Compositional Structures (SYCO)

The Symposium on Compositional Structures is a new interdisciplinary meeting aiming to support the growing community of researchers interested in the phenomenon of compositionality, from both applied and abstract perspectives, and in particular where category theory serves as a unifying common language.

We welcome submissions from researchers across computer science, mathematics, physics, philosophy, and beyond, with the aim of fostering discussion, disseminating new ideas, and spreading knowledge of open problems between fields. Submission is encouraged for both mature research and work in progress, and by both established academics and junior researchers, including students. The meeting does not have proceedings.

While no list of topics could be exhaustive, SYCO welcomes submissions with a compositional focus related any the following areas, in particular from the perspective of category theory:

• logical methods in computer science, including quantum and classical programming, concurrency, natural language processing and machine learning;

• graphical calculi, including string diagrams, Petri nets and reaction networks;

• languages and frameworks, including process algebras, proof nets, type theory and game semantics;

• abstract algebra and pure category theory, including monoidal category theory, higher category theory, operads, polygraphs, and relationships to homotopy theory;

• quantum algebra, including quantum computation and representation theory;

• tools and techniques, including rewriting, formal proofs and proof assistants;

• industrial applications, including case studies and real-world problem descriptions.

Meetings

Meetings will involve both invited and contributed talks. The first meeting is planned for Autumn 2018, with more details to follow soon.

Funding

Some funding may be available to support travel and subsistence, especially for junior researchers who are speaking at the meeting.

Steering committee

The symposium is managed by the following people:

• Ross Duncan, University of Strathclyde.
• Chris Heunen, University of Edinburgh.
• Aleks Kissinger, Radboud University Nijmegen.
• Samuel Mimram, École Polytechnique.
• Mehrnoosh Sadrzadeh, Queen Mary.
• Pawel Sobocinski, University of Southampton.
• Jamie Vicary, University of Birmingham and University of Oxford.

The Physics of Butterfly Wings

Some butterflies have shiny, vividly colored wings. From different angles you see different colors. This effect is called iridescence. How does it work?

It turns out these butterfly wings are made of very fancy materials! Light bounces around inside these materials in a tricky way. Sunlight of different colors winds up reflecting off these materials in different directions.

We’re starting to understand the materials and make similar substances in the lab. They’re called photonic crystals. They have amazing properties.

Here at the Centre for Quantum Technologies we have people studying exotic materials of many kinds. Next door, there’s a lab completely devoted to studying graphene: crystal sheets of carbon in which electrons can move as if they were massless particles! Graphene has a lot of potential for building new technologies—that’s why Singapore is pumping money into researching it.

Some physicists at MIT just showed that one of the materials in butterfly wings might act like a 3d form of graphene. In graphene, electrons can only move easily in 2 directions. In this new material, electrons could move in all 3 directions, acting as if they had no mass.

The pictures here show the microscopic structure of two materials found in butterfly wings:

The picture at left actually shows a sculpture made by the mathematical artist Bathsheba Grossman. But it’s a piece of a gyroid: a surface with a very complicated shape, which repeats forever in 3 directions. It’s called a minimal surface because you can’t shrink its area by tweaking it just a little. It divides space into two regions.

The gyroid was discovered in 1970 by a mathematician, Alan Schoen. It’s a triply periodic minimal surfaces, meaning one that repeats itself in 3 different directions in space, like a crystal.

Schoen was working for NASA, and his idea was to use the gyroid for building ultra-light, super-strong structures. But that didn’t happen. Research doesn’t move in predictable directions.

In 1983, people discovered that in some mixtures of oil and water, the oil naturally forms a gyroid. The sheets of oil try to minimize their area, so it’s not surprising that they form a minimal surface. Something else makes this surface be a gyroid—I’m not sure what.

Butterfly wings are made of a hard material called chitin. Around 2008, people discovered that the chitin in some iridescent butterfly wings is made in a gyroid pattern! The spacing in this pattern is very small, about one wavelength of visible light. This makes light move through this material in a complicated way, which depends on the light’s color and the direction it’s moving.

So: butterflies have naturally evolved a photonic crystal based on a gyroid!

The universe is awesome, but it’s not magic. A mathematical pattern is beautiful if it’s a simple solution to at least one simple problem. This is why beautiful patterns naturally bring themselves into existence: they’re the simplest ways for certain things to happen. Darwinian evolution helps out: it scans through trillions of possibilities and finds solutions to problems. So, we should expect life to be packed with mathematically beautiful patterns… and it is.

The picture at right above shows a ‘double gyroid’. Here it is again:

This is actually two interlocking surfaces, shown in red and blue. You can get them by writing the gyroid as a level surface:

and taking the two nearby surfaces

for some small value of .

It turns out that while they’re still growing, some butterflies have a double gyroid pattern in their wings. This turns into a single gyroid when they grow up!

The new research at MIT studied how an electron would move through a double gyroid pattern. They calculated its dispersion relation: how the speed of the electron would depend on its energy and the direction it’s moving.

An ordinary particle moves faster if it has more energy. But a massless particle, like a photon, moves at the same speed no matter what energy it has. The MIT team showed that an electron in a double gyroid pattern moves at a speed that doesn’t depend much on its energy. So, in some ways this electron acts like a massless particle.

But it’s quite different than a photon. It’s actually more like a neutrino! You see, unlike photons, electrons and neutrinos are spin-1/2 particles. Neutrinos are almost massless. A massless spin-1/2 particle can have a built-in handedness, spinning in only one direction around its axis of motion. Such a particle is called a Weyl spinor. The MIT team showed that a electron moving through a double gyroid acts approximately like a Weyl spinor!

How does this work? Well, the key fact is that the double gyroid has a built-in handedness, or chirality. It comes in a left-handed and right-handed form. You can see the handedness quite clearly in Grossman’s sculpture of the ordinary gyroid:

Beware: nobody has actually made electrons act like Weyl spinors in the lab yet. The MIT team just found a way that should work. Someday someone will actually make it happen, probably in less than a decade. And later, someone will do amazing things with this ability. I don’t know what. Maybe the butterflies know!

References and more

For a good introduction to the physics of gyroids, see:

• James A. Dolan, Bodo D. Wilts, Silvia Vignolini, Jeremy J. Baumberg, Ullrich Steiner and Timothy D. Wilkinson, Optical properties of gyroid structured materials: from photonic crystals to metamaterials, Advanced Optical Materials 3 (2015), 12–32.

For some of the history and math of gyroids, see Alan Schoen’s webpage:

• Alan Schoen, Triply-periodic minimal surfaces.

For more on gyroids in butterfly wings, see:

• K. Michielsen and D. G. Stavenga, Gyroid cuticular structures in butterfly wing scales: biological photonic crystals.

• Vinodkumar Saranathana et al, Structure, function, and self-assembly of single network gyroid (I4₁32) photonic crystals in butterfly wing scales, PNAS 107 (2010), 11676–11681.

The paper by Michielsen and Stavenga is free online! They say the famous ‘blue Morpho’ butterfly shown in the picture at the top of this article does not use a gyroid; it uses a “two-dimensional photonic crystal slab consisting of arrays of rectangles formed by lamellae and microribs.” But they find gyroids in four other species: Callophrys rubi, Cyanophrys remus, Pardes sesostris and Teinopalpus imperialis. It compares tunnelling electron microscope pictures of slices of their iridescent patches with computer-generated slices of gyroids. The comparison looks pretty good to me:

For the evolution of iridescence, see:

• Melissa G. Meadows et al, Iridescence: views from many angles, J. Roy. Soc. Interface 6 (2009).

For the new research at MIT, see:

• Ling Lu, Liang Fu, John D. Joannopoulos and Marin Soljačić, Weyl points and line nodes in gapless gyroid photonic crystals.

• Ling Lu, Zhiyu Wang, Dexin Ye, Lixin Ran, Liang Fu, John D. Joannopoulos and Marin Soljačić, Experimental observation of Weyl points, Science 349 (2015), 622–624.

Again, the first is free online. There’s a lot of great math lurking inside, most of which is too mind-blowing too explain quickly. Let me just paraphrase the start of the paper, so at least experts can get the idea:

Two-dimensional (2d) electrons and photons at the energies and frequencies of Dirac points exhibit extraordinary features. As the best example, almost all the remarkable properties of graphene are tied to the massless Dirac fermions at its Fermi level. Topologically, Dirac cones are not only the critical points for 2d phase transitions but also the unique surface manifestation of a topologically gapped 3d bulk. In a similar way, it is expected that if a material could be found that exhibits a 3d linear dispersion relation, it would also display a wide range of interesting physics phenomena. The associated 3D linear point degeneracies are called “Weyl points”. In the past year, there have been a few studies of Weyl fermions in electronics. The associated Fermi-arc surface states, quantum Hall effect, novel transport properties and a realization of the Adler–Bell–Jackiw anomaly are also expected. However, no observation of Weyl points has been reported. Here, we present a theoretical discovery and detailed numerical investigation of frequency-isolated Weyl points in perturbed double-gyroid photonic crystals along with their complete phase diagrams and their topologically protected surface states.

Also a bit for the mathematicians:

Weyl points are topologically stable objects in the 3d Brillouin zone: they act as monopoles of Berry flux in momentum space, and hence are intimately related to the topological invariant known as the Chern number. The Chern number can be defined for a single bulk band or a set of bands, where the Chern numbers of the individual bands are summed, on any closed 2d surface in the 3d Brillouin zone. The difference of the Chern numbers defined on two surfaces, of all bands below the Weyl point frequencies, equals the sum of the chiralities of the Weyl points enclosed in between the two surfaces.

This is a mix of topology and physics jargon that may be hard for pure mathematicians to understand, but I’ll be glad to translate if there’s interest.

For starters, a ‘monopole of Berry flux in momentum space’ is a poetic way of talking about a twisted complex line bundle over the space of allowed energy-momenta of the electron in the double gyroid. We get a twist at every ‘Weyl point’, meaning a point where the dispersion relations look locally like those of a Weyl spinor when its energy-momentum is near zero. Near such a point, the dispersion relations are a Fourier-transformed version of the Weyl equation.

Quantum Frontiers in Network Science

guest post by Jacob Biamonte

There’s going to be a workshop on quantum network theory in Berkeley this June. The event is being organized by some of my collaborators and will be a satellite of the biggest annual network science conference, NetSci.

A theme of the Network Theory series here on Azimuth has been to merge ideas appearing in quantum theory with other disciplines. Remember the first post by John which outlined the goal of a general theory of networks? Well, everyone’s been chipping away at this stuff for a few years now and I think you’ll agree that this workshop seems like an excellent way to push these topics even further, particularly as they apply to complex networks.

The event is being organized by Mauro Faccin, Filippo Radicchi and Zoltán Zimborás. You might recall when Tomi Johnson first explained to us some ideas connecting quantum physics with the concepts of complex networks (see Quantum Network Theory Part 1 and Part 2). Tomi’s going to be speaking at this event. I understand there is even still a little bit of space left to contribute talks and/or to attend. I suspect that those interested can sort this out by emailing the organizers or just follow the instructions to submit an abstract.

They have named their event Quantum Frontiers in Network Science or QNET for short. Here’s their call.

Quantum Frontiers in Network Science

This year the biggest annual network science conference, NetSci will take place in Berkeley California on 2-6 June. We are organizing a one-day Satellite Workshop on Quantum Frontiers in Network Science (QNET).

A grand challenge in contemporary complex network science is to reconcile the staple “statistical mechanics based approach” with a theory based on quantum physics. When considering networks where quantum coherence effects play a non-trivial role, the predictive power of complex network science has been shown to break down. A new theory is now being developed which is based on quantum theory, from first principles. Network theory is a diverse subject which developed independently in several disciplines to rely on graphs with additional structure to model complex systems. Network science has of course played a significant role in quantum theory, for example in topics such as tensor network states, chiral quantum walks on complex networks, categorical tensor networks, and categorical models of quantum circuits, to name only a few. However, the ideas of complex network science are only now starting to be united with modern quantum theory. From this respect, one aim of the workshop is to put in contact two big and generally not very well connected scientific communities: statistical and quantum physicists.

The topic of network science underwent a revolution when it was realized that systems such as social or transport networks could be interrelated through common network properties, but what are the relevant properties to consider when facing quantum systems? This question is particularly timely as there has been a recent push towards studying increasingly larger quantum mechanical systems, where the analysis is only beginning to undergo a shift towards embracing the concepts of complex networks.

For example, theoretical and experimental attention has turned to explaining transport in photosynthetic complexes comprising tens to hundreds of molecules and thousands of atoms using quantum mechanics. Likewise, in condensed matter physics using the language of “chiral quantum walks”, the topological structure of the interconnections comprising complex materials strongly affects their transport properties.

An ultimate goal is a mathematical theory and formal description which pinpoints the similarities and differences between the use of networks throughout the quantum sciences. This would give rise to a theory of networks augmenting the current statistical mechanics approach to complex network structure, evolution, and process with a new theory based on quantum mechanics.

Topics of special interest to the satellite include

• Quantum transport and chiral quantum walks on complex networks
• Detecting community structure in quantum systems
• Tensor algebra and multiplex networks
• Quantum information measures (such as entropy) applied to complex networks
• Quantum critical phenomena in complex networks
• Quantum models of network growth
• Quantum techniques for reaction networks
• Quantum algorithms for problems in complex network science
• Foundations of quantum theory in relation to complex networks and processes thereon
• Quantum inspired mathematics as a foundation for network science

Info

QNET will be held at the NetSci Conference venue at the Clark Kerr Campus of the University of California, on June 2nd in the morning (8am-1pm).

Links

• Main conference page: NetSci2014
• Call for abstracts and the program

It sounds interesting! You’ll notice that the list of topics seems reminiscent of some of the things we’ve been talking about right here on Azimuth! A general theme of the Network Theory Series has been geared towards developing frameworks to describe networked systems through a common language and then to map the use of tools and results across disciplines. It seems like a great place to talk about these ideas. Oh, and here’s a current list of the speakers:

• Leonardo Banchi (UCL, London)
• Ginestra Bianconi (London)
• Silvano Garnerone (IQC, Waterloo)
• Laetitia Gauvin (ISI Foundation)
• Marco Javarone (Sassari)
• Tomi Johnson (Oxford)

and again, the organizers are

• Mauro Faccin (ISI Foundation)
• Filippo Radicchi (Indiana University)
• Zoltán Zimborás (UCL)

From the call, we can notice that a central discussion topic at QNET will be about contrasting stochastic and quantum mechanics. Here on Azimuth we like this stuff. You might remember that stochastic mechanics was formulated in the network theory series to mathematically resemble quantum theory (see e.g. Part 12). This formalism was then employed to produce several results, including a stochastic version of Noether’s theorem by John and Brendan in Parts 11 and 13—recently Ville has also written Noether’s Theorem: Quantum vs Stochastic. Several other results were produced by relating quantum field theory to Petri nets from population biology and to chemical reaction networks in chemistry (see the Network Theory homepage). It seems to me that people attending QNET will be interested in these sorts of things, as well as other related topics.

One of the features of complex network science is that it is often numerically based and geared directly towards interesting real-world applications. I suspect some interesting results should stem from the discussions that will take place at this workshop.

By the way, here’s a view of downtown San Francisco at dusk from Berkeley Hills California from the NetSci homepage:

Network Theory I



Here’s a video of a talk I gave last Tuesday—part of a series. You can see the slides here:

• Network Theory I: electrical circuits and signal-flow graphs.

Click on items in blue, or pictures, for more information.

One reason I’m glad I gave this talk is because afterwards Jamie Vicary pointed out some very interesting consequences of the relations among signal-flow diagrams listed in my talk. It turns out they imply equations familiar from the theory of complementarity in categorical quantum mechanics!

This is the kind of mathematical surprise that makes life worthwhile for me. It seemed utterly shocking at first, but I think I’ve figured out why it happens. Now is not the time to explain… but I’ll have to do it soon, both here and in the paper that Jason Eberle are writing about control theory.

For now, besides the slides, the best place to read more about this program is here:

• Brendan Fong, A compositional approach to control theory.

The Elitzur–Vaidman Bomb-Testing Method

Quantum mechanics forces us to refine our attitude to counterfactual conditionals: questions about what would have happened if we had done something, even though we didn’t.

“What would the position of the particle be if I’d measured that… when actually I measured its momentum?” Here you’ll usually get no definite answer.

But sometimes you can use quantum mechanics to find out what would have happened if you’d done something… when classically it seems impossible!

Suppose you have a bunch of bombs. Some have a sensor that will absorb a photon you shine on it, and make the bomb explode! Others have a broken sensor, that won’t interact with the photon at all.

Can you choose some working bombs? You can tell if a bomb works by shining a photon on it. But if it works, it blows up—and then it doesn’t work anymore!

So, it sounds impossible. But with quantum mechanics you can do it. You can find some bombs that would have exploded if you had shone photons at them!

Here’s how:

Put a light that emits a single photon at A. Have the photon hit the half-silvered mirror at lower left, so it has a 50% chance of going through to the right, and a 50% chance of reflecting and going up. But in quantum mechanics, it sort of does both!

Put a bomb at B. Recombine the photon’s paths using two more mirrors. Have the two paths meet at a second half-silvered mirror at upper right. You can make it so that if the bomb doesn’t work, the photon interferes with itself and definitely goes to C, not D.

But if the bomb works, it absorbs the photon and explodes unless the photon takes the top route… in which case, when it hits the second half-silvered mirror, it has a 50% chance of going to C and a 50% chance of going to D.

So:

• If the bomb doesn’t work, the photon has a 100% chance of going to C.

• If the bomb works, there’s a 50% chance that it absorbs the photon and explodes. There’s also a 50% chance that the bomb does not explode—and then the photon is equally likely to go to either C or D. So, the photon has a 25% chance of reaching C and a 25% chance of reaching D.

So: if you see a photon at D, you know you have a working bomb… but the bomb has not exploded!

For each working bomb there’s:

• a 50% chance that it explodes,
• a 25% chance that it doesn’t explode but you can’t tell if it works,
• a 25% chance that it doesn’t explode but you can tell that it works.

This is the Elitzur–Vaidman bomb-testing method. It was invented by Avshalom Elitzur and Lev Vaidman in 1993. One year later, physicists actually did an experiment to show this idea works… but alas, not using actual bombs!

In 1996, Kwiat showed that using more clever methods, you can reduce the percentage of wasted working bombs as close to zero as you like. And pushing the idea even further, Graeme Mitchison and Richard Jozsa showed in 1999 that you can get a quantum computer to do a calculation for you without even turning it on!

This sounds amazing, but it’s really no more amazing than the bomb-testing method I’ve already described.

References

For details, read these:

• A. Elitzur and L. Vaidman, Quantum mechanical interaction-free measurements, Found. Phys. 23 (1993), 987–997.

• Paul G. Kwiat, H. Weinfurter, T. Herzog, A. Zeilinger, and M. Kasevich, Experimental realization of “interaction-free” measurements.

• Paul G. Kwiat, Interaction-free measurements.

• Graeme Mitchison and Richard Jozsa, Counterfactual computation, Proc. Roy. Soc. Lond. A457 (2001), 1175–1194.

The picture is from the Wikipedia article, which also has other references:

• Elitzur–Vaidman bomb tester, Wikipedia.

Bas Spitters pointed out this category-theoretic analysis of the issue:

• Robert Furber and Bart Jacobs, Towards a categorical account of conditional probability.

Centre for Quantum Mathematics and Computation

This fall they’re opening a new Centre for Quantum Mathematics and Computation at Oxford University. They’ll be working on diagrammatic methods for topology and quantum theory, quantum gravity, and computation. You’ll understand what this means if you know the work of the people involved:

• Samson Abramsky
• Bob Coecke
• Christopher Douglas
• Kobi Kremnitzer
• Steve Simon
• Ulrike Tillman
• Jamie Vicary

All these people are already at Oxford, so you may wonder what’s new about this center. I’m not completely sure, but they’ve gotten money from EPSRC (roughly speaking, the British NSF), and they’re already hiring a postdoc. Applications are due on March 11, so hurry up if you’re interested!

They’re having a conference October 1st to 4th to start things off. I’ll be speaking there, and they tell me that Steve Awodey, Alexander Beilinson, Lucien Hardy, Martin Hyland, Chris Isham, Dana Scott, and Anton Zeilinger have been invited too.

I’m really looking forward to seeing Chris Isham, since he’s one of the most honest and critical thinkers about quantum gravity and the big difficulties we have in understanding this subject—and he has trouble taking airplane flights, so it’s been a long time since I’ve seen him. It’ll also be great to see all the other people I know, and meet the ones I don’t.

For example, back in the 1990’s, I used to spend summers in Cambridge talking about n-categories with Martin Hyland and his students Eugenia Cheng, Tom Leinster and Aaron Lauda (who had been an undergraduate at U.C. Riverside). And more recently I’ve been talking a lot with Jamie Vicary about categories and quantum computation—since was in Singapore some of the time while I was there. (Indeed, I’m going back there this summer, and so will he.)

I’m not as big on n-categories and quantum gravity as I used to be, but I’m still interested in the foundations of quantum theory and how it’s connected to computation, so I think I can give a talk with some new ideas in it.

Quantum Computing Position at U.C. Riverside



Here at U.C. Riverside, Alexander Korotkov wants to hire a postdoc in quantum measurement and quantum computing with superconducting qubits.

He writes:

The work will be mainly related to quantum feedback of superconducting qubits. The first experiment was published in Nature today. (Some News & Views discussion can be seen here.) The theory is still rather simple and needs improvement.



Time Crystals

When water freezes and forms a crystal, it creates a periodic pattern in space. Could there be something that crystallizes to form a periodic pattern in time? Frank Wilczek, who won the Nobel Prize for helping explain why quarks and gluons trapped inside a proton or neutron act like freely moving particles when you examine them very close up, dreamt up this idea and called it a time crystal:

• Frank Wilczek, Classical time crystals.

• Frank Wilczek, Quantum time crystals.

‘Time crystals’ sound like something from Greg Egan’s Orthogonal trilogy, set in a universe where there’s no fundamental distinction between time and space. But Wilczek wanted to realize these in our universe.

Of course, it’s easy to make a system that behaves in an approximately periodic way while it slowly runs down: that’s how a clock works: tick tock, tick tock, tick tock… But a system that keeps ‘ticking away’ without using up any resource or running down would be a strange new thing. There’s no telling what weird stuff we might do with it.

It’s also interesting because physicists love symmetry. In ordinary physics there are two very important symmetries: spatial translation symmetry, and time translation symmetry. Spatial translation symmetry says that if you move an experiment any amount to the left or right, it works the same way. Time translation symmetry says that if you do an experiment any amount of time earlier or later, it works the same way.

Crystals are fascinating because they ‘spontaneously break’ spatial translation symmetry. Take a liquid, cool it until it freezes, and it forms a crystal which does not look the same if you move it any amount to the right or left. It only looks the same if you move it certain discrete steps to the right or left!

The idea of a ‘time crystal’ is that it’s a system that spontaneously breaks time translation symmetry.

Given how much physicists have studied time translation symmetry and spontaneous symmetry breaking, it’s sort of shocking that nobody before 2012 wrote about this possibility. Or maybe someone did—but I haven’t heard about it.

It takes real creativity to think of an idea so radical yet so simple. But Wilczek is famously creative. For example, he came up with anyons: a new kind of particle, neither boson nor fermion, that lives in a universe where space is 2-dimensional. And now we can make those in the lab.

Unfortunately, Wilczek didn’t know how to make a time crystal. But now a team including Xiang Zhang (seated) and Tongcang Li (standing) at U.C. Berkeley have a plan for how to do it.

Actually they propose a ring-shaped system that’s periodic in time and also in space, as shown in the picture. They call it a space-time crystal:

Here we propose a space-time crystal of trapped ions and a method to realize it experimentally by confining ions in a ring-shaped trapping potential with a static magnetic field. The ions spontaneously form a spatial ring crystal due to Coulomb repulsion. This ion crystal can rotate persistently at the lowest quantum energy state in magnetic fields with fractional fluxes. The persistent rotation of trapped ions produces the temporal order, leading to the formation of a space-time crystal. We show that these space-time crystals are robust for direct experimental observation. The proposed space-time crystals of trapped ions provide a new dimension for exploring many-body physics and emerging properties of matter.

The new paper is here:

• Tongcang Li, Zhe-Xuan Gong, Zhang-Qi Yin, H. T. Quan, Xiaobo Yin, Peng Zhang, L.-M. Duan and Xiang Zhang, Space-time crystals of trapped ions.

Alas, the press release put out by Lawrence Berkeley National Laboratory is very misleading. It describes the space-time crystal as a clock that

will theoretically persist even after the rest of our universe reaches entropy, thermodynamic equilibrium or “heat-death”.

NO!

First of all, ‘reaching entropy’ doesn’t mean anything. More importantly, as time goes by and things fall apart, this space-time crystal, assuming anyone can actually make it, will also fall apart.

I know what the person talking to the reporter was trying to say: the cool thing about this setup is that it gives a system that’s truly time-periodic, not gradually using up some resource and running down like an ordinary clock. But nonphysicist readers, seeing an article entitled ‘A Clock that Will Last Forever’, may be fooled into thinking this setup is, umm, a clock that will last forever. It’s not.

If this setup were the whole universe, it might keep ticking away forever. But in fact it’s just a small, carefully crafted portion of our universe, and it interacts with the rest of our universe, so it will gradually fall apart when everything else does… or in fact much sooner: as soon as the scientists running it turn off the experiment.

Classifying space-time crystals

What could we do with space-time crystals? It’s way too early to tell, at least for me. But since I’m a mathematician, I’d be happy to classify them. Over on Google+, William Rutiser asked if there are 4d analogs of the 3d crystallographic groups. And the answer is yes! Mathematicians with too much time on their hands have classified the analogues of crystallographic groups in 4 dimensions:

• Space group: classification in small dimensions, Wikipedia.

In general these groups are called space groups (see the article for the definition). In 1 dimension there are just two, namely the symmetry groups of this:

— o — o — o — o — o — o —

and this:

— > — > — > — > — > — > —

In 2 dimensions there are 17 and they’re called wallpaper groups. In 3 dimensions there are 230 and they are called crystallographic groups. In 4 dimensions there are 4894, in 5 dimensions there are… hey, Wikipedia leaves this space blank in their table!… and in 6 dimensions there are 28,934,974.

So, there is in principle quite a large subject to study here, if people can figure out how to build a variety of space-time crystals.

There’s already book on this, if you’re interested:

• Harold Brown, Rolf Bulow, Joachim Neubuser, Hans Wondratschek and Hans Zassenhaus, Crystallographic Groups of Four-Dimensional Space, Wiley Monographs in Crystallography, 1978.

Quantizing Electrical Circuits

As you may know, there’s a wonderful and famous analogy between classical mechanics and electrical circuit theory. I explained it back in “week288”, so I won’t repeat that story now. If you don’t know what I’m talking about, take a look!

This analogy opens up the possibility of quantizing electrical circuits by straightforwardly copying the way we quantize classical mechanics problems. I’d often wondered if this would be useful.

It is, and people have done it:

• Michel H. Devoret, Quantum fluctuations in electrical circuits.

Michel Devoret, Rob Schoelkopf and others call this idea quantronics: the study of mesoscopic electronic effects in which collective degrees of freedom like currents and voltages behave quantum mechanically.

I just learned about this from a talk by Sean Barrett here in Coogee. There are lots of cool applications, but right now I’m mainly interested in how this extends the set of analogies between different physical theories.

One interesting thing is how they quantize circuits with resistors. Over in classical mechanics, this corresponds to systems with friction. These systems, called ‘dissipative’ systems, don’t have a conserved energy. More precisely, energy leaks out of the system under consideration and gets transferred to the environment in the form of heat. It’s hard to quantize systems where energy isn’t conserved, so people in quantronics model resistors as infinite chains of inductors and capacitors: see the ‘LC ladder circuit’ on page 15 of Devoret’s notes. This idea is also the basis of the Caldeira–Leggett model of a particle coupled to a heat bath made of harmonic oscillators: it amounts to including the environment as part of the system being studied.

A Quantum Hammersley–Clifford Theorem

I’m at this workshop:

• Sydney Quantum Information Theory Workshop: Coogee 2012, 30 January – 2 February 2012, Coogee Bay Hotel, Coogee, Sydney, organized by Stephen Bartlett, Gavin Brennen, Andrew Doherty and Tom Stace.

Right now David Poulin is speaking about a quantum version of the Hammersley–Clifford theorem, which is a theorem about Markov networks. Let me quickly say a bit about what he proved! This will be a bit rough, since I’m doing it live…

The mutual information between two random variables is

The conditional mutual information between three random variables is

It’s the average amount of information about learned by measuring when you already knew

All this works for both classical (Shannon) and quantum (von Neumann) entropy. So, when we say ‘random variable’ above, we
could mean it in the traditional classical sense or in the quantum sense.

If then has the following Markov property: if you know learning tells you nothing new about In condensed matter physics, say a spin system, we get (quantum) random variables from measuring what’s going on in regions, and we have short range entanglement if when corresponds to some sufficiently thick region separating the regions and We’ll get this in any Gibbs state of a spin chain with a local Hamiltonian.

A Markov network is a graph with random variables at vertices (and thus subsets of vertices) such that whenever is a subset of vertices that completely ‘shields’ the subset from the subset : any path from to goes through a vertex in a

The Hammersley–Clifford theorem says that in the classical case we can get any Markov network from the Gibbs state

of a local Hamiltonian and vice versa. Here a Hamiltonian is local if it is a sum of terms, one depending on the degrees of freedom in each clique in the graph:

Hayden, Jozsa, Petz and Winter gave a quantum generalization of one direction of this result to graphs that are just ‘chains’, like this:

o—o—o—o—o—o—o—o—o—o—o—o

Namely: for such graphs, any quantum Markov network is the Gibbs state of some local Hamiltonian. Now Poulin has shown the same for all graphs. But the converse is, in general, false. If the different terms in a local Hamiltonian all commute, its Gibbs state will have the Markov property. But otherwise, it may not.

For some related material, see:

• David Poulin, Quantum graphical models and belief propagation.
